QNAP NAS 5100
NAS-5100, QNAP's high performance 1U NAS Controller, is adopting advanced 64 bit BUS technology with 19" industrial standard chassis.
Featuring Intel Pentium III Tualatin CPU, built-in 1GB ECC DRAM, dual Gigabit Ethernet for fail-over and load-balance, two SCSI Ultra 320 VHDCI interfaces, NAS-5100 offers the extreme flexibility for external storage expansion such as SCSI hard disk drives, RAID subsystems, and tape drives.
It optimizes your storage resources and brings easy management for application in e-commerce and capability for higher-level server integration in the office.
QNAP's NAS 5100 Controller is combined into multiple solutions, ranging from just 1.6 TB to 25.6 TB. The latest industry RAID solutions from several leading storage manufacturers can be combined with QNAP NAS 5100 Controller, to create a robust data storage solution.
(Any Ultra 160 or Ultra 320 SCSI connected RAID solution, including IDE to SCSI can be used to connect to the NAS 5100 controller, although for support direct from SQS Ltd any RAID box used must be on our certified RAID solutions list, which is available on request)
Upto four independant SCSI RAID boxes (all of which could be running RAID 5) can be connected to the NAS 5100, and then in turn the NAS 5100 will create a RAID 5 data set from the four RAID boxes. This then creates a very fault tolerant, fast Network Attatched Storage resource.
Every NAS 5100 can also be replicated to another NAS 5100, or even to a NAS 4300 or NAS 4120B (NAS 4300 & NAS 4120B scheduled only), real time or on a scheduled basis for the ultimate corporate business data protection solution.
You may wish to replicate on a real time basis the accounts database, which is held on the volume Accounts, but the the General volume which contains less important information may only need to be replicated once a day, say at 2am thus saving network bandwidth. Replication can also or course be acheived over a WAN connection.
Combine all this with an Ultra 320 LVD SCSI interface as standard on the NAS 5100 and you have a real high performance NAS solution that will meet and exceed all your performance expectations. You can scale from 1 TB to 16 TB easily. No other product combines the range of enterprise level features with such a competitive price point.
- NAS 5100 Solutions scale from just 1.6 TB to 25.6 Terabytes
- REAL TIME Remote Replication between Disk Arrays
- Firmware updates available by subscription to QNAP.co.uk
- Built In Snap Shot Software
- Control all data storage from any browser on the network
- Now available with upto 25.6 Terabytes of storage !!
- NAS 5100 + 4 RAID Arrays create a very robust storage resource
- RAID 5 Disk Arrays can be run in a RAID 5 configuration
- A total RAID Disk Array can fail and your data remains intact
- Combine NAS 5100 with ExpreStor RAID solutions
Product Features
New Challenge Among Enterprises
-- Leveraging the investment in storage to create resources that profit
With the rapid adoption of e-commerce and e-business, it has become a new challenge for most enterprises to keep the services up-and-running on 24/7 while maintaining data protection and reducing the total cost of ownership.
QNAP's Intelligent NAS Controller
-- Storage with flexibility to meet the requirement for enterprises
QNAP's intelligent NAS controller offers the utmost efficiency and scalability to meet the growing demand in the storage for enterprises. It also gives the flexibility to fit into various types of applications to meet the requirements for growing enterprises such as cross-platform file management and sharing, order processing, e-commerce, and expandable external storage devices-SCSI hard disk drives, RAID subsystems, and tape drives.
Product Highlights
High Usability--Real Time Remote Replication
Supporting real time remote replication of important data, NAS-5100 enables important corporate data to be preserved in a more reliable fashion, such that critical data do not get lost in a catastrophe. When remote file directory and local file directory are setup correctly, synchronization of specified directories will be duplicated at the remote matching directory. The remote replication is optimized such that duplication only includes the difference in file updates at any time. When files in the local directory are deleted, the files at the remote directory will also be deleted accordingly.
High Expandability--Optimized Storage Resources
At the heart of NAS-5100, we have applied dual Ultra 320 SCSI interface, providing high-speed data transfer passage. The external expandable disk array system is very stable and fast, providing reliable data protection. And the maximum storage capacity of 16TB fits the current increasing demand from enterprise users. The integrated intelligent network attached storage engine and DAS provides the ability to separate service and data, as well as longevity of corporate investment in data storage. Also, the real time remote replication function increases the usability and reliability of data storage, making next generation corporations highly competent.
High Performance--Mission Critical Task Executed Flawlessly
NAS-5100 is the most optimized 1U rack-mount network attached storage solution in the market. It utilizes 64bit PCI bus to resolve the bottleneck in data transfer speed of traditional network attached storage devices. With Intel processor and built-in 1GB Error Check and Correction (ECC) RAM, NAS-5100 supports fully loaded dual Gigabit Ethernet, load balancing, fault tolerance, as well as two sets of SCSI Ultra 320 VHDCI high-speed bus interface.
Lowest Ownership Cost--The Most Cost-effective Long Term Investment
NAS-5100 provides the best possibility for enterprise budget planning. The web interface is user friendly and easy for installation. Maintenance and configuration is very intuitive, eliminating the need for complicated IT management. NAS-5100 is carefully designed to be a 1U rack-mount chassis, to provide best flexibility in hardware and software integration for server room or remote company subsidiary location, real time read/write of database, and global database management. All of these are to ensure flexibility and expandability for optimized corporate data management and long-term corporate operation
CPU |
Intel Pentium III Tualatin 1 GHz |
Flash Memory |
32MB |
DRAM |
1GB ECC memory |
Chipset |
ServerWorks LE-T (Advanced 64-bit PCI Technology) |
Software |
NASWare Advanced Edition |
Other I/O |
SCSI Interface |
2-Channel 64-bit PCI Ultra 320 for SCSI HDD
External RAID Subsystem / Tape Drive |
USB 1.1 Interface |
UPS Power Management Support |
RS232 Interface |
UPS Power Management Support |
System
Information |
LED Indicator |
Power, Error, Network Status, HDD |
LCD Display |
LCD High Brightness Panel,
Two control Buttons for System Management |
Alarm Buzzer |
System Malfunction Warning |
Network
Specification |
Network Standards |
IEEE802.3 10Base-T Ethernet
IEEE802.3u 100Base-TX Ethernet
IEEE802.3ab 1000Base-T Ethernet
IEEE802.3x Flow Control
ANSI/IEEE 802.3 Nway Auto-negotiation |
Gigabit Ethernet |
2 x 10/100/1000Mbps Auto-Sensing Ethernet Ports
(RJ-45 Interface) |
LAN Ports |
1 x 10/100Mbps Auto-Sensing Ethernet Ports
(Only for OEM/ODM) |
Physical
Specification |
Form Factor |
19" 1U Rack-mount |
Dimension |
429(D) x 430(W) x 44(H) mm |
Weight |
Net Weight: 6 KG Gross Weight: 9KG |
Operation Environment |
Temperature |
0 ~ 45 o C |
Humidity |
0 ~ 95% R.H |
Power
Management |
|
Power Supply Specification |
ATX Power Supply,90~264V |
| QNAP NAS 5100 - Bare Unit (No RAID Storage) |
£2,195 |
 |
| Don't miss out on total peace of mind with our complete remote & on-site support packages. |
| QNAP NAS 5100 - Installation |
£245.00 |
|
| QNAP NAS 5100 - 12 Months On Site Maintenance |
£395.00 |
|
| QNAP NAS 5100 - 24 Months On Site Maintenance |
£711.00 |
|
| QNAP NAS 5100 - 36 Months On Site Maintenance |
£948.00 |
|
All prices quoted on our website are subject to change without notice & exclude Delivery & VAT.
Please see our Terms and Conditions for more details.
All QNAP products are covered by free technical support direct from the manufacturer. However you can upgrade any QNAP product to include Gold Support, local technical support provided by SQS engineers in Reading , Berkshire , via our Technical@sqsonline.com service. Technical@sqsonline.com utilises the services of GoToMyPC. All onsite maintenance contracts include Gold Support for the duration of the onsite maintenance contract. SQS Ltd does not provide any direct technical support for any product that is not covered either by an onsite maintenance contract or by a Gold Support contract. All contracts must be valid and payment must have been made in full prior to any technical support request. Gold Support and onsite maintenance contracts are available to purchase only when making an initial hardware purchase. Service level upgrade to either onsite maintenance or Gold Support is not available after delivery.
