The NAS-4030 is currently the only QNAP network storage servers to adopt triple Gigabit Ethernet technology, offering exceptional solutions for users requiring a desktop storage unit. The NAS-4030 utilises the Advanced Edition of QNAP firmware.
Triple Gigabit Ethernet: The NAS-4030 offers three gigabit etherent connections. Autosensing they allow three 10 / 100 or 1000 connections to be made to the NAS unit for increased data throughput and reliability.
Hardware Redundancy Protection: The NAS-4030 offers hardware redundancy protection over its components that can be plugged and unplugged while the system is in operation. This provides continuous data and system availability with no downtime.
Hot Swappable Hard Drives: The NAS-4030 features 4 hot-swappable hard drives to avoid downtime of business critical data availability and the possible loss of data. The hot swappable feature provides data protection in the event of an individual drive failure, the drive can be removed and a new drive can be plugged in without shutting down the system.
While the NAS-4030 unit operating in RAID 5 or 1 disk management, the bad drive can be removed and replaced with a new drive as a hot-spare. Our proprietary Operation System NASware OS will automatically configure the replacement drive and reconstruct the data from the lost drive and allow work to continue without interruption.
Hot Swappable and Redundant Power Supplies: To prevent failure of system components is a key ingredient of sustaining zero downtime in accessing vital business information. The design-in of redundant and hot-swappable power supplies makes the NAS-4030 continuing to operate in the event of a failure of power. The failed power supply can be replaced without interrupting service and provide high data availability at all time
- Available from 1.2TB to 2TB
- Includes Snapshot support for even greater data protection
- Intel Celeron 1.7GHz Processor
- 256MB of high performance memory
- RAID 0, 1, 5, JBOD, and Individual Disk data protection
- Hardware Fail-Over Redundancy Protection
- Redundant and Hot-swappable power supplies.
- Hot-swappable Hard Drives
- Support all major Network Operating Systems
- Including Windows, MAC, Linux/Unix, Novell Netware
- Autosensing Triple (3) 10/100/Gigabit Ethernet
- DHCP Server
- Microsoft NT Domain Controller (PDC)
- Firmware updates available by subscription to QNAP.co.uk
- Installation in a minutes
- Set-up via LCD display or web interface
- Web-based Management
- Firmware update through web interface
- No User Licenses
- Instant storage file sharing via LAN for office or department
- Personal entertainment archive
- DVR system storage expansion
- NAS 4030 Solutions Include A Standard 2 Years RTB Warranty
| Hardware Spec |
|
| System Spec |
|
CPU |
NAS-4020 : Intel Celeron 850MHz
NAS-4030 : Intel Celeron 1.7GHz |
Flash Memory |
NAS-4020 : 16MB Flash
NAS-4030 : 32MB Flash |
Memory |
NAS-4020 : 1 x 128 MB
NAS-4030 : 1 x 256 MB |
| Storage Spec |
|
Hard Disk |
4 x 3.5" IDE Hotswap HD, up to 1200 GB |
Network Spec |
|
LAN Ports |
NAS-4020 : 1 x 10/100/1000 Mbps RJ-45 Ethernet Port
NAS-4030 : 3 x 10/100/1000 Mbps RJ-45 Ethernet Port |
Physical Spec |
|
Form Factor |
Desktop |
Dimension |
380mm(D) x 168mm(W) x 240mm(H) |
Weight |
Net Weight : 10KG Gross Weight : 14KG |
| Operation Environment |
|
Temperature |
0~45 |
Humidity |
0~95% R.H |
Power Management |
|
Power Supply Spec |
NAS-4020 : 2 x ATX Redundant Power Supply, 150W, 90~264VAV
NAS-4030 : 2 x ATX Redundant Power Supply, 165W, 90~264VAV |
| Software Spec |
NasWare 2 |
Operation System |
Linux Embedded System |
Network Transport Protocols |
TCP/IP, IPX, NetBEUI, Apple Talk |
Network File Protocols |
Microsoft Networks (CIFS/SMB), Apple (AFP), UNIX (NFS), Internet (HTTP), Novell Network (NCP), File Transfer Protocol (FTP) |
Network Security |
Microsoft Network Domain Controller (PDC)
Microsoft AD Authentication(NAS-4030 only) |
Network Client Type |
Microsoft Windows 95/98/ME/NT/2000/XP/2003, Macintosh system 7.5+, Linux/UNIX, Novell |
Network Configuration |
Dynamic IP Address, Fixed IP Address, DHCP Service
Network load balance and fail over (NAS-4030 only) |
Disk Configuration |
RAID 0 (Stripping), RAID 1 (Mirroring), JBOD (Liner Disk Volume), RAID 5(Distributed Parity), Single disk |
Disk Management |
Hard Disk Failure Detection (S.M.A.R.T), Disk Detect/Auto Recovery, Disk Used Status Management |
File System Management |
Journaling File System, Web File Manager for Remote Access, Over 2 GB Files Support (Windows Networking, FTP, NFS V3), Users quota settingMicrosoft ACL support, Snapshot(NAS-4030 only) |
System Management |
Web-based administration, SNMP Support, System Temperature MonitorE-mail alert, LCD Panel display, LED display, Alarm buzzer, System Software upgrade, Support Network Time Protocol, Multi users account settingOn line virus scan, Schedule shutdown and boot (NAS-4030 only) |
System Setup and Configuration |
Web-based GUI for system administration, Quick Install WizardLCD Panel Configuration, Reset Button |
Multi Language Support |
English, Traditional Chinese, Simplified Chinese, Japanese, French, German,Danish, Dutch, Finnish, Italian, Korean, Norwegian, Portuguese, Russian, Spanish, Swedish(NAS-4020 only) |
UPS Support |
SNMP |
Backup Management |
Support Client Backup Software NetBak Replicator, Schedule to remote replication backup, Support Most Popular Network Backup Application |
Event Log |
Display all current login users, Display system log/alert/error, Display all DHCP distribution log |
